The SH470 crawler excavator is a 44.9-ton heavy-duty machine developed for mining, rock excavation, infrastructure earthworks and high-volume material handling.
Its 250 kW power system, 236 kN bucket digging force and 2.0–2.2 m³ bucket provide strong penetration and loading performance in hard soil, gravel and demanding excavation conditions.
A high-performance main pump and Toshiba main control valve help deliver accurate hydraulic control and smooth movement coordination. The machine also features a 5.7-inch color monitor, adjustable suspension seat and automatic climate-control system.
Mining, quarrying, rock excavation, overburden removal, bulk earthworks, road construction, foundation excavation and large infrastructure projects.
| Item | Specification |
|---|---|
| Model | SH470 |
| Operating weight | 44,900 kg |
| Rated power | 250 kW at 2,000 rpm |
| Bucket capacity | 2.0–2.2 m³ |
| Overall dimensions | 12,090 × 3,490 × 3,590 mm |
| Track length | 5,335 mm |
| Track shoe width | 600 mm |
| Travel speed | 5.3 / 3.2 km/h |
| Gradeability | 70% / 35° |
| Bucket digging force | 236 kN |
| Maximum traction force | 270 kN |
| Fuel tank | 650 L |
| Hydraulic oil capacity | 350 / 450 L |
| Engine oil capacity | 37.8 L |
